· Integrated inductor, MOSFETs and controlle𝐆r
· Input ꦬvoltage operating range f🌄rom 2.9V to 5.5V
· Fixed and programmable VOUT from 1.0V
· Up to 1A typical output current
· Up to 93% efficiency at 5VIN, 3.3VOUT/0.6A
· Ultra-low IQ of 40µA
· Constant-On-Time (COT) control ไscheme
· Ultrafast transient response
·&nbs🌼p;3MHz PWM operation in continuous mode
· 100% duty cycle in dropout
· Enable pin control
· Internal soft-start
· Thermal shutdown
· Small Footprint, low profile
3mm × 3mm × 0.9mm QFN-13 package
The IM6001 is a 1A step-down power module which integrated inductor, MOSFETs and controller in one tiny package, perfectly suiting for any space constrained application. Operating over an input voltage range of 2.9V to 5✱.5V, the module supports an output voltage range from 1V to VIN by 100% duty cycle control. For programmable output, only two FB resistors and input and output capacitors are needed to complete the design, while the FB resistors can be removed in fixed output design. This results a simplification in supply chain and inventory management, and he🐬lps to enable an overall cost savings.
3MHz switching frequency and constant on-time🌜 control scheme architecture deliver a very fast transient response to line and load changes without sacrificing stability. It also features an internal soft-start function and offers protection features including input UVLO, cycle-by-cycle current limit, output short-circuit protection and thermal shutdown.
